Saturday, August 10, 2013

Second Pipeline Mapped Out

Walked the Kiwanis trail today and found the famous blue stakes, so I followed them and mapped out the new pipeline until it enters the Frye Farm. Just to make sure, I did not enter into any marked private property and did not encounter any fences - I just followed the stakes from the public walkway shown in the first picture just below until back to the Kiwanis trail.










This gave me the general direction, where this straight part of the pipeline meets the straight portion crossing M52 and passing the residence shown in a picture on a previous post. My last guess was actually pretty close.

 There are 3 bottom holes off Carson, which all seem to be located on the Frye farm. The new pipeline is in red and refers to the elevation profile below the map. I also marked all current bottom holes on Witt Farm (Adrian 1-25), Purse Funeral Home (State Adrian & Purse 2-25), Statton's Landscaping (State Adrian & Stratton 1-24), and Heritage Park (Adrian Raisin 2-30)). Please note that many of these wells exploit several locations by drilling horizontally. Old pipeline from Heritage to Witt in blue

I check out if I could see anything of the two bottom holes in the southwestern corner of Frye Farm and was thrilled that I could get a peak just west of the Kiwanis trail that was not marked as private property and was not fenced in. Please note that I did not step on the open grassland, which is obviously private property...
Unfortunately, there was nothing to be seen. Frye 1-26 may not been drilled yet ??? and Frye 2-26 is in the forest and not visible (or is also not drilled yet???).

 The forest opening in the middle of the picture leads to Frye 2-26 but it goes way into the forest
The Frye farmhouse with a excavator and already assembled pipes for the pipeline.

 Shortly after the above pictures, Kiwanis trail crosses Beaver Creek. The bottom hole Frye 2-26 (Carson 4) is 30 ft. right above the creek. Frye 1-26 (Carson 3) is a little further away but also just 40 ft. above the creek bed. It is very easy for contaminated ground water or surface water to reach the creek.

Frye 2-26 (Carson 4) is 30 ft. right above the creek (see profile above), Frye 1-26 (Carson 3) is 40 ft above the creek bed.


Oils residue above mud in a ditch next to Kiwanis trail close to Frye 1-26



Beaver Creek towards NW as seen from the Kiwanis trail bridge



Tuesday, May 7, 2013

Pipeline Goes Underground in Heritage Park

The pipes that will be buried into the flood plain are still above ground. Note the almost 90° angle from the straight down direction from the drill site towards Beaver Creek. This shows that the originally staked track will be simplified by going diagonal through part of the disc golf lawn and then cut straight through to the already laid straight track on the farm sites above the floodplain.


The five metal pipes buried 4 ft crossing the field road to the disc golf area.  Please note the still high level of ground water under the pipes.
The connection to the flood plain pipes still needs to be made.
 Ground water level is still very high. The pipes would sit in water if lowered into the trench.
 Closeup to where the pipes cross the disc golf service road. You can clearly see the 5 metal pipes and a sixth plastic pipe (what for?)
 Strange attachments on pipes waiting to be buried. Are these floating devices - but what about the wires?
Asphalt gravel is distributed and is spread out over the road crossing using a caterpillar.


On the North side of the service road towards the Heritage drilling site, the pipes leave the 4 ft. trench and have to be carefully lifted into trench  step by step.


On the way back from our walk (40 minutes later), 5 metal pipes are inside of the trench facing the floodplain. A sixth metal pipe is still outside. In some areas the pipes look very zig-zaggy - not very trustworthy...

But still have to be laid underground one-by-one for another 50 yards towards the Heritage Park drilling site.

At the same pace the excavator progresses some 100 yards ahead towards the drill site.
